Simple P5 WebRTC
Include this library in a p5 sketch and share audio/video streams or the canvas itself as a stream. Can also share data (string only for now). All WebRTC so Peer to Peer.
Running a public signaling server on https://p5livemedia.itp.io - Run your own signalling server by running server.js (with Node, Express and Socket.io).
Requires simplepeer and socket.io be included in the HTML:
<script type="text/javascript" src="https://p5livemedia.itp.io/simplepeer.min.js"></script>
<script type="text/javascript" src="https://p5livemedia.itp.io/socket.io.js"></script>
Of course, this library needs to be included as well:
<script type="text/javascript" src="https://p5livemedia.itp.io/p5livemedia.js"></script>
Use the callback from createCapture to get at the media stream.
Instantiate p5Live with:
- a reference to the sketch (this)
- a string indicating if this is audio/video ("CAPTURE") or a canvas ("CANVAS")
- the media stream from the createCapture callback
- and a unique room name. The sketch id from the p5 editor works well (in this case, "jZQ64AMJc").
Add a callback for the "stream" event, in this case, a function defined later called "gotStream":
let myVideo = null;
function setup() {
createCanvas(400,400);
myVideo = createCapture(VIDEO,
function(stream) {
let p5lm = new p5LiveMedia(this, "CAPTURE", stream, "jZQ64AMJc")
p5lm.on('stream', gotStream);
}
);
}
You can specify the normal MediaStreamConstraints to specify framerates, sizes, and stream types. You'll want to mute your local video to prevent feedback:
let myVideo = null;
function setup() {
createCanvas(400,400);
let constraints = {audio: true, video: true};
myVideo = createCapture(constraints,
function(stream) {
let p5lm = new p5LiveMedia(this, "CAPTURE", stream, "jZQ64AMJc")
p5lm.on('stream', gotStream);
}
);
myVideo.elt.muted = true;
}
The "stream" callback gives a normal video element:
let otherVideo;
function gotStream(stream, id) {
otherVideo = stream;
//otherVideo.id and id are the same and unique identifier
}
Both video elements can be used in the draw loop:
function draw() {
if (myVideo != null) {
image(myVideo,0,0,width/2,height);
text("My Video", 10, 10);
}
if (otherVideo != null) {
image(otherVideo,width/2,0,width/2,height);
text("Their Video", width/2+10, 10);
}
}
Alternatively the p5 Canvas can be streamed instead of video:
let otherCanvas;
function setup() {
let myCanvas = createCanvas(400, 400);
let p5lm = new p5LiveMedia(this, "CANVAS", myCanvas, "e4LTqKI8Q");
p5lm.on('stream', gotStream);
}
function draw() {
background(220);
fill(255,0,0);
ellipse(mouseX,mouseY,100,100);
}
function gotStream(stream) {
otherCanvas = stream;
}
Streaming a Canvas and Audio is a little more involved:
let myAudio;
let myCanvas;
let otherVideo;
function setup() {
myCanvas = createCanvas(400, 400);
// Use constraints to request audio from createCapture
let constraints = {
audio: true
};
// Need to use the callback to get at the audio/video stream
myAudio = createCapture(constraints, function(stream) {
// Get a stream from the canvas to send
let canvasStream = myCanvas.elt.captureStream(15);
// Extract the audio tracks from the stream
let audioTracks = stream.getAudioTracks();
// Use the first audio track, add it to the canvas stream
if (audioTracks.length > 0) {
canvasStream.addTrack(audioTracks[0]);
}
// Give the canvas stream to SimpleSimplePeer as a "CAPTURE" stream
let p5lm = new p5LiveMedia(this, "CAPTURE", canvasStream, "SimpleSimplePeerAdvancedTest");
p5lm.on('stream', gotStream);
});
myAudio.elt.muted = true;
myAudio.hide();
}
function draw() {
background(220);
fill(255,0,0);
ellipse(mouseX,mouseY,100,100);
}
function gotStream(stream) {
otherVideo = stream;
}
data can be shared between connected users (a data connection is always available between the connected users). To use you'll need to implement an additional callback for "data":
let otherX = 0;
let otherY = 0;
let ssp;
function setup() {
createCanvas(400, 400);
// Passing in "DATA" as the capture type but data sharing works with "CAPTURE" and "CANVAS" as well
p5lm = new p5LiveMedia(this, "DATA", null, "w83C-S6DU");
// "data" callback
p5lm.on('data', gotData);
}
function draw() {
background(220);
fill(255,0,0);
ellipse(mouseX,mouseY,100,100);
fill(0,255,0);
ellipse(otherX,otherY,100,100);
}
function gotData(data, id) {
print(id + ":" + data);
// If it is JSON, parse it
let d = JSON.parse(data);
otherX = d.x;
otherY = d.y;
}
function mouseMoved() {
// Package as JSON to send
let dataToSend = {x: mouseX, y: mouseY};
// Send it
p5lm.send(JSON.stringify(dataToSend));
}
Each callback also includes an "id" to indicate who is sending the stream or data and there is a "disconnect" callback when a user disconnects:
p5lm.on('data', gotData);
function gotData(theData, id) {
}
p5lm.on('stream', gotStream);
function gotStream(theStream, id) {
}
p5lm.on('disconnect', gotDisconnect);
function gotDisconnect(id) {
}
More documentation forthcoming.
- Basic Video Example
- Basic Audio/Video Example (video overlayed)
- Basic Canvas Example
- Video on Canvas Example
- Another Video on Canvas Example
- Data Only
- Multiple Users Overlayed
- Multiple Users 3D with Data
- ADVANCED: 3D Shared Space
- ADVANCED: Manipulated Video on Canvas + Audio
- ADVANCED: 50 Days of Video Chat
Contributed Examples
- Video + Data
- Flocking Video
- ADVANCED: Frame Differencing
- Simple Multiple Users
- Mutiple Users Associative Array
- Mutliple Users with Data
- Three.js Integration: Example Sending AV Stream from a Capture Object: code live
- Three.js Integration: Sending Data to Move AV Stream from Capture Object: code live
- Three.js Integration: Example Sending from a Canvas: code live
